Hitec D85MG 32-Bit Metal Gear Micro Servo

Description

D85MG 32-Bit Metal Gear Micro Servo from Hitec – HRC36085S

Engineered with state-of-the-art D-Series technology, this “micro but mighty” servo is an upgrade from the HS-5085MG. With soft-start enabled circuitry, 4096 high-resolution and a long-life potentiometer, the D85MG allows for smooth and decisive movement and accuracy. Programmable application-specific parameters provide the ultimate in maximum servo performance. This servo is Ideal for 3m gliders; < 40 oz. 3D airplanes; < 70 oz. scale planes and 1/16 or smaller surface vehicles (no internal combustion engines, electric only).

Features:

• 32-Bit MCU with 12-Bit ADC Circuitry
• 4096 Resolution
• 1M Cycle Long Life Potentiometer
• Ball Bearing Supported Output Shaft
• 3-Pole, Metal Brushed, Ferrite Motor
• Nylon Reinforced Plastic Case

Programmable Functions:

• End Point Adjustments
• Direction
• Fail Safe
• Dead Band
• Speed (Slower)
• Data Save / Load
• Program Reset

Includes:

• Hitec D85MG 32-Bit Metal Gear Micro Servo
• Horns and mounting gear
