Description
Servo Overview:
Reefs 299LP High Torque/Speed Brushless Low Profile High Voltage Servo. Available in multiple anodized colors with a beautiful aluminum case, this powerful racing servo features a water-resistant low-profile design with a magnetic angle sensor and is capable of putting out 313oz-in (22.5kg-cm) of torque and 0.05sec/60° of speed at (8.4V)! Providing racers and drifters the speed and power needed in a low-profile, lightweight sleek design!
Features:
- Hi voltage capable
- High torque high speed brushless motor
- Water resistant low profile design
- Magnetic angle sensor
- Fully programmable with REEFS software (Reefs LINK required for programming)
- All aluminum case with side fins to maximize heat dissipation
- Anodized in multiple colors
Specifications:
- Speed:
- @6.0V:0.07sec/60°
- @7.4V:0.06sec/60°
- @8.4V:0.05sec/60°
- Torque:
- @6.0V:278oz-in (20kg-cm)
- @7.4V:299oz-in (21.5kg-cm)
- @8.4V:313oz-in (22.5kg-cm)
- Motor:Brushless
- Operating Voltage:4.8V-8.4V
- Dimensions(LxWxH):1.6″x0.79″x1.0″ (40.8×20.2×26.5mm)
- Weight:2.0oz (57.2g)
- Operating Spline:25T (ProTek/Futaba)
Includes:
- (1) 299LP Low-Profile Racing Servo
- Servo Horns and Mounting Hardware
This product was added to our catalog on February 8, 2019
Kevin Klein Thursday, Jun 4 2020 (about 5 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) I got this servo from my LHS and put in my new Yokomo YZ-2 CAL3 and holy moly this servo is fast and strong. I have been a fan of the Protek 160T and Spektrum 6240 for my 1/10 rigs but this servo is my new favorite. Great job Reefs. 6 customers found this review helpful. Anonymous Verified Owner Saturday, Feb 23 2019 (about 6 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) I installed this servo in my EB410 yesterday (Friday, Feb 22, 2019). After installation, I was setting end-points and trimming out steering and noticed how quiet and smooth this servo seemed to operate. In addition to smooth, quiet operation, the end-point adjustment setting was in the high 80s (percent) in both directions. Most of the higher torque servos I own have end-point settings are down in the higher 60s (percent) AND seem to vary widely in both directions. This is important to me because after adjusting end-points on other servos, I notice I have no steering. So, I need to re-adjust end-points back up to a higher number. This tells me that to achieve the steering I need, I must risk damage to the buggy or servo. With this servo, I didn’t have that problem. I had all the steering needed without stressing the servo or buggy. Again, a very quiet servo with almost zero buzz when stressed, under load at maximum throw in either direction. Given the price of this servo, buyers can get a powerful brushless servo in a full aluminum case (bottom of the case, too) at the cost of servos with less features. 6 of 8 customers found this review helpful. Ryan Fournel Monday, Jan 24 2022 (about 3 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) I bought the 299LP servo for my mew B74 build. This servo is amazing! Super fast! More than enough torque for a mod 4wd buggy! I switched my b6.3d servo to a REEFS RC 299LP servo as well! Best 1/10 racing servo hands down! Solid, powerful, super fast, programmable servo with a price that can’t be beat! 1 customer found this review helpful. Bill Deras Thursday, Oct 21 2021 (about 3 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) Also important to know that Reefs has this servo rate as being SUBMERSIBLE WATERPROOF. And I can attest to that. 1 customer found this review helpful. Timothy Buchanan Verified Owner Wednesday, Mar 17 2021 (about 4 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) I’ve owned many different brands of servos but reefs is favorite now. I own the 777 amd 299lp and their both best of the best. 1 customer found this review helpful. Kenneth Compton Jr Verified Owner Thursday, May 23 2024 (about a year ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) Super fast light and durable great choice for any drag car in my opinion. Alex Rizi Verified Owner Friday, Mar 8 2024 (about a year ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) This servo is just amazing. My new favorite servo at this price point and also programmable. I love that you can also set Sanwa SSR and Futaba SR mode for even more feeling out of this impressive servo (USB programmer needed for this). Sorry Protek but I just sold all my 160TBL and only getting these servos from now on. The protek had too much deadband at neutral which I don’t like and also the reefs is much stronger at any voltage 6volt (amazing) and at 7.4 volts or more this servo is just insane. The only servo that I like more than this one is the MKS 599sl but it cost way more. Highly recommended.
This servo was tested in a 2wd buggy and in my wheeler B74.2D both at 6 volts. scott lenig Verified Owner Tuesday, Dec 19 2023 (about a year ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) Best all around servo for the price. super fast and super strong. Paul Verified Owner Tuesday, Jun 27 2023 (about 2 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) Bought two for a 21.5t Cougar & 8.5t XLS Cat and love ’em. Super quick, strong and look good too. Nathan Teague Verified Owner Thursday, Apr 13 2023 (about 2 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) Perfect quality, I have used Reefs servos on my crawlers and street cars for a while now. I will say that this is by far the best for the money. Chris Lopez Verified Owner Monday, Apr 18 2022 (about 3 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) Best servo I have ever used!! Highly recommend!!…………….. Curt Partain Verified Owner Monday, Feb 7 2022 (about 3 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) Excellent compact Servo very responsive and accurate. Got it fast from AMain Hobby James Martin Verified Owner Friday, Nov 1 2024 (11 months ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) I love the face of equipment so far haven’t got a chance to test it but it’s very smooth 0 of 1 customers found this review helpful. Reginald King Verified Owner Thursday, Jan 20 2022 (about 3 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) Fast shipping but I was expecting this servo to be stronger than stock. I’m sure it will outlast a stock servo,but I’m not sure this is the strongest one 1 of 8 customers found this review helpful. Richard Edwards Verified Owner Thursday, Mar 26 2020 (about 5 years ago) Reefs RC 299LP High Torque/Speed Brushless Low Profile Servo (High Voltage) Biggest waste of money. I purchased this servo for rear steering on my axial Capra. After 15 minutes of use the steering began acting like it had 0 power then would glitch out. After a reset on the truck I got the servo back for about a minute and with no load on the chassis and tires you could hear grinding. The end points were set correct and there was a bec connected and it was set to 6 volts. I guess all the rumors are true concerning the company “reefs”. Never again will I buy a product made by reefs or will I purchase a product that is recommended by the company. Biggest waste of money ever. Do yourself a favor and stay away. 2 of 23 customers found this review helpful. View all reviews
